Product Summary

The SFH4244-Z is a high power infrared emitter (940 nm).

Parametrics

SFH4244-Z absolute maximum ratings: (1)Operating and storage temperature range, Top/Tstg: -40 to + 100℃; (2)Reverse voltage, VR: 5V; (3)Forward current, IF: 70mA; (4)Surge current, IFSM: 700mA; (5)Power dissipation, Ptot: 140mW.

Features

SFH4244-Z features: (1)High Power Infrared LED; (2)Short switching times.

Diagrams

SFH4244-Z Package Outlines
