Product Summary
The DX-5R5H334U is a 5.5V electric double layer capacitor. It is smaller and lighter than Series DB. With 5mm tall. Max. thin profile (H-shaped), the DX-5R5H334U is in miniaturized but can encase up to 0.33F in 11.5×5mm case, and 1.5F in 19.0×20.5mm case. Its package / case is through hole - horizontal. And its Equivalent Series Resistance is 75.00 Ohm.
Parametrics
Parameters: (1)Family: Supercaps, Ultracaps, Aerogel, Electric Double Layer; (2)Tolerance: ±30%; (3)Series: DX; (4)Capacitance: 330mF; (5)Voltage - Rated: 5.5V; (6)Mounting Type: Through Hole; (7)Lead Spacing: 0.394" (10.00mm); (8)Package / Case: Through Hole - Horizontal; (9)Lifetime @ Temp.: 1000 Hrs @ 70℃; (10)Maximum Temperature: -25℃to 70℃; (11)ESR (Equivalent Series Resistance): 75.00 Ohm.
Features
Features: (1)Smaller and lighter than Series DB; (2)5mm tall. Max. thin profile(H-shaped); (3)Miniaturized but can encase up to 0.33F in 11.5x5mm case.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 DX-5R5H334U |
Elna |
Supercapacitors / Ultracapacitors H/MOUNT 5.5V 0.33F |
Data Sheet |
|
|
||||||||||||
