PIC16HV616-I/SL

flash-based, 8-bit, CMOS microcontroller, 2KX14, 14SOIC, 20MHz

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.70~0.75 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.70~0.75

PartNumber:: PIC16HV616-I/SL

Brand:: Microchip Technology - Microchip | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Amanda's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-11

From Other Seller

Part Number:PIC16HV616-I/SL
US $0.70 - 0.75
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PIC16HV616-I/SL is a 14-Pin, flash-based 8-bit CMOS microcontroller.

Parametrics

PIC16HV616-I/SL absolute maximum ratings: (1)Ambient temperature under bias: -40℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on VDD with respect to VSS: -0.3V to +6.5V; (4)Voltage on MCLR with respect to Vss: -0.3V to +13.5V; (5)Voltage on all other pins with respect to VSS: -0.3V to (VDD + 0.3V); (6)Total power dissipation: 800 mW; (7)Maximum current out of VSS pin: 95 mA; (8)Maximum current into VDD pin: 95 mA; (9)Input clamp current, IIK (VI < 0 or VI > VDD): ± 20 mA; (10)Output clamp current, IOK (Vo < 0 or Vo >VDD): ± 20 mA; (11)Maximum output current sunk by any I/O pin: 25 mA; (12)Maximum output current sourced by any I/O pin: 25 mA; (13)Maximum current sunk by PORTA and PORTC (combined): 90 mA; (14)Maximum current sourced PORTA and PORTC (combined): 90 mA.

Features

PIC16HV616-I/SL features: (1)Industrial and Extended Temperature Range; (2)Power-on Reset (POR); (3)Power-up Timer (PWRT) and Oscillator Start-up Timer (OST); (4)Brown-out Reset (BOR); (5)Watchdog Timer (WDT) with Independent Oscillator for Reliable Operation; (6)Multiplexed Master Clear with Pull-up/Input Pin; (7)Programmable Code Protection; (8)High Endurance Flash: 100,000 write Flash endurance; (9)Flash retention: > 40 years.
